The wear-resistant Ultrathan® Prädifa AF wiper ring serves to prevent the ingress of dust, dirt, sand, and swarf into the hydraulic cylinder. This reduces the risk of scoring on the piston rod caused by external contamination embedded in the guidance. The good wiping effect is achieved by the special design of the wiper lip.
The proven Parker Praedifa P5008 polyurethane compound stands for abrasion resistance, minor permanent deformation, and robustness against external mechanical impact. The wiper is securely held in place in the axially open groove via press-fit of the metal jacket vis-à-vis the inner groove diameter. As the wiper lip is flush with the cylinder head it is largely protected against external mechanical damage.
- Robust seal profile for harshest operating conditions.
- Extreme wear resistance
- Suitable for fully automatic installation
- Dimensions according to DIN ISO 6195, Type B
- Simple fabrication of the housing
Range of application
Hydraulic cylinders and valve tappets
Operating temperature -35 °C to +100 °C
Sliding speed ≤ 2 m/s
Compounds
Standard material of the elastomer part is Ultrathan® P5008, a polyurethane-based Parker compound with a hardness of approx. 93 Shore A. In comparison with other polyurethane materials currently available on the market, it excels because of its increased heat and wears resistance.
Installation
The profile AF Ultrathan® wiper rings are manufactured with a slightly oversized outer diameter D, thus ensuring a secure press-fit in the groove DH8 after installation. Any contact of the wiper lip with piston rod eyes or other connecting parts should be avoided.
d | D | L | a | Order code | d | D | L | a | Order code | |
20 | 30 | 7 | 1 | AF2030Z5071* | 90 | 100 | 7 | 1 | AF9020Z5071 | |
25 | 35 | 7 | 1 | AF2535Z5071* | 90 | 104 | 8 | 1.5 | AF9033Z5071 | |
30 | 40 | 6 | 1 | AF3040Z5071 | 90 | 105 | 6 | 1 | AF9030Z5071 | |
36 | 48 | 6 | 1 | AF3648Z5071 | 90 | 110 | 10 | 2 | AF9037Z5071 | |
40 | 50 | 7 | 1 | AF4050Z5071* | 95 | 109 | 8 | 1.5 | AF9505Z5071 | |
40 | 52 | 6 | 1 | AF4052Z5071 | 100 | 115 | 7 | 1 | AFA016Z5071 | |
45 | 55 | 7 | 1 | AF4555Z5071* | 100 | 115 | 9 | 1.5 | AFA015Z5071* | |
45 | 60 | 7.5 | 1 | AF4560Z5071 | 100 | 120 | 10 | 2 | AFA021Z5071 | |
50 | 60 | 7 | 1 | AF5060Z5071* | 101.6 | 114 | 8 | 1.5 | AFA024Z5071 | |
50 | 65 | 7.5 | 1 | AF5064Z5071 | 110 | 125 | 9 | 1.5 | AFB025Z5071 | |
56 | 70 | 7.5 | 1 | AF5656Z5071 | 110 | 126 | 9 | 1.5 | AFB009Z5071 | |
57.15 | 69.96 | 7.92 | 1.5 | AF5715Z5071 | 110 | 130 | 10 | 2 | AFB011Z5071 | |
60 | 70 | 7 | 1 | AF6005Z5071 | 120 | 140 | 8 | 1.5 | AFC023Z5071 | |
60 | 74 | 8 | 1.5 | AF6008Z5107 | 120 | 140 | 10 | 2 | AFC024Z5071 | |
60 | 75 | – | 0.7 | AF6028Z5071 | 125 | 140 | 9 | 2 | AFC514Z5071* | |
63 | 73 | 7 | 1 | AF6375Z5071 | ||||||
63 | 78 | 7.5 | 1 | AF6378Z5071 | ||||||
65 | 79 | 8 | 1.5 | AF6505Z5071 | ||||||
65 | 80 | 5 | 0.7 | AF6509Z5071 | ||||||
69.85 | 95.4 | 12.7 | 2 | AF6908Z5071* | ||||||
70 | 80 | 7 | 1 | AF7005Z5071 | ||||||
70 | 84 | 8 | 1.5 | AF7016Z5071 | ||||||
70 | 85 | 7.5 | 1 | AF7085Z5071 | ||||||
71 | 86 | 5 | 0.7 | AF7110Z5071 | ||||||
75 | 89 | 8 | 1.5 | AF7537Z5071 | ||||||
75 | 90 | 5 | 0.7 | AF7590Z5071 | ||||||
76.5 | 96.5 | 10 | 2 | AF7696Z5071* | ||||||
80 | 90 | 7 | 1 | AF8090Z5071* | ||||||
80 | 94 | 8 | 1.5 | AF8013Z5071 | ||||||
80 | 95 | 5 | 0.7 | AF8005Z5071 | ||||||
80 | 100 | 10 | 2 | AF8021Z5071 | ||||||
82.55 | 108.08 | 12.7 | 2 | AF8205Z5071* | ||||||
85 | 99 | 8 | 1.5 | AF8509Z5071 | ||||||
85 | 105 | 10 | 2 | AF8515Z5071* |
